Debunking electrification myths
February 28, 2023
Sam Calisch
The author would like to thank Steve Pantano, Leah Stokes, Ari Matusiak, Sarah Lazarovic, and Joel Rosenberg of Rewiring America for helping bring this piece together.
[1] Renewable natural gas is also sometimes called sustainable natural gas, biogas, biomethane, marsh gas, sewer gas, compost gas, swamp gas and a host of other names. Sometimes these other names are used to refer to the raw feedstock gasses, while renewable natural gas is reserved for the gas after it has been “upgraded”, or refined to pipeline quality.
[2] For example, see this 2022 McKinsey report, this 2022 American Gas Foundation report, or this 2022 report from University of Utah. Utilities frequently release plans incorporating renewable natural gas, like this 2021 report from SoCalGas and this 2020 report from Washington Gas.
On a larger scale, a December 2022 House Oversight Committee report documents how methane management has been used as “social license” by Big Oil companies to continue investing in fossil fuel production. For example, an internal email from the American Petroleum Institute, states that the group’s climate policy specifically promoted the continued use of natural gas.
[3] Hydrogen and other “clean fuels” are often proposed alongside renewable natural gas in this proposition. In the context of building decarbonization, these other energy carriers also have a host of issues. For instance, a 2022 report assessing viability of hydrogen proposals found serious concerns about safety, cost and scale for distributing hydrogen for building decarbonization. A 2021 report found that just 7 percent of the gas energy delivered could be replaced with hydrogen, and that hydrogen leaked at three times the rate of fossil gas. Reporting in 2022 showed evidence that studies touting hydrogen have been funded and influenced by the gas industry. For simplicity, we only discuss RNG in this piece, and will address these other energy carriers in future work.
[4] All natural gas varies in chemical composition, but is chiefly composed of methane. The percentage of methane present in fossil gas at the wellhead can vary a great deal, and must be purified before entering a pipeline. According to Fundamentals of Natural Gas Processing, “pipeline quality gas” consists of a minimum of 75 percent methane, and a maximum of 10 percent ethane, 5 percent propane, 2 percent butanes, 0.5 percent pentanes and heavier hydrocarbons, 3 percent nitrogen and other inert gasses, 3 percent carbon dioxide. There are also limits on the maximum amount of hydrogen sulfide, total sulfur, oxygen and water vapor present. Renewable natural gas must be upgraded to these same pipeline quality standards from the raw biogas feedstock. After this refining, the methane content of the renewable natural gas is the same as fossil natural gas, but the trace gasses present may still vary, according to a 2021 EPA report.
[5] A 2021 study found that the majority of U.S. urban natural gas emissions were not accounted for in greenhouse gas inventories, finding an average leak rate between 3.3 and 4.7 percent from well to urban customer. A 2018 study found that methane emissions were 60 percent higher than previously estimated by the EPA, meaning approximately 2.3 percent of the U.S. gross fossil gas production is lost to leaks. A 2021 study showed that rates of production stage leaks alone contribute between 0.9 and 3.6 percent, adding approximately 40-160 percent to the equivalent emissions of combustion. Other studies have found even higher values, for example a 2011 study estimated the leak rate at 3.6 percent to 7.9 percent. A 2021 study looked at post-meter leaks in natural gas stoves, finding they leaked 0.8-1.3 percent of the gas they consumed. A 2020 study found water heaters leaked 0.39-0.93 percent of the gas they consumed.
It is worth noting that “certified” natural gas (also called “differentiated” natural gas, or “responsibly sourced” gas) refers to natural gas from a facility with a low rate of methane leakage, but these certifications (like the MiQ standard) only focus on leakage from production and do not address leaks in distribution or on-site use. This 2022 report from the Environmental Defense Fund presents detailed concerns about the mitigation potential of these certifications, including a lack of standards for measurement, the limited uptake, and the incentives for companies to “cherry-pick” within their energy portfolios.
[6] Taking a conservative estimate of 3% leakage rate, the 20 year global warming potential of methane of 81.2, the emissions factor of natural gas of 53 kg CO2e / MMBTU, a heat content of 1,037 BTU per cubic foot, a proportion of methane in natural gas of 97 percent, and a density of natural gas of 0.8 kilograms per cubic meter, we find that for every kilogram of carbon emissions released from combustion, approximately 0.98 kilograms of equivalent carbon emissions are released from methane leaks. This means that roughly half of total emissions from using natural gas come from methane leaks.
[7] In a 2019 survey of renewable natural gas plants, the average leakage rate was 4.6 percent, roughly double the gas industry average even before including transmission, distribution, and combustion. At this leakage rate, renewable natural gas retains over two-thirds the emissions of fossil gas. Wastewater treatment plants, a major source of renewable natural gas, were even higher at 7.5 percent on average, with some plants as high as 15 percent. A 2020 report found that for leakage rates above 6 percent, the equivalent emissions of intentionally produced RNG is actually higher than that of conventional fossil gas. That is, for leakage rates observed in existing facilities, emissions from RNG are just as high as fossil gas.
[8] Critically, the destruction removal efficiency of flaring must be greater than that of the downstream gas infrastructure plus eventual combustion. A 2014 study suggests flaring efficiency is above 98 percent, but a 2022 study shows that flaring in oil and gas fields can regularly be as low as 91 percent, emphasizing the need for careful control and monitoring.
[9] According to a 2020 article, the total amount of capturable methane sources currently being vented is less than 1 percent of the current fossil gas resource. Applying the climate benefits of these sources to a hypothetical RNG system capable of meeting any significant portion of current fossil gas demand is not realistic. To have an RNG system that can meet our demands, the feedstocks would very likely be intentionally produced. Because RNG from such intentionally produced methane streams does not mitigate an existing source of emissions, it has approximately equivalent emissions to fossil gas.
[10] Argonne National Lab tracks RNG facilities and maintains up-to-date counts of existing and planned facilities. As of 2020, there were approximately 60 trillion BTU per year of RNG produced. Of these, approximately 46 trillion BTUs came from landfills, 7 trillion from livestock, 4 trillion from food waste, and 3 trillion from wastewater treatment. This amounts to approximately 0.2 percent of U.S. natural gas consumption, according to the EIA’s Natural Gas Consumption by End Use.
[11] The USDA’s Biogas Opportunities Roadmap estimates there exist about 13,000 sites in the U.S. that could host a biogas system (about 2,000 of them are currently built out). Taken together, these potential sites could generate 650 billion cubic feet of gas per year (or about 350 trillion BTU per year). Critically, this biogas is made up chiefly of methane (40-60 percent) and carbon dioxide (30-50 percent). This means the usable (methane) portion of this biogas is roughly 360 billion cubic feet. In NREL’s Biogas Potential of the United States, the authors estimate the methane potential from landfill material, animal manure, wastewater, and industrial, institutional, and commercial organic waste at 420 billion cubic feet (430 trillion BTU per year).
While this may sound like a lot of gas, the U.S. consumption of fossil gas in 2020 was over 30 trillion cubic feet per year according to the EIA’s Natural Gas Consumption by End Use. This means if the infrastructure required to convert, harvest, collect, transport, and distribute the biogas from all potential sources in the U.S., the total technical potential of methane production by organic sources is just 1.3 percent of national consumption. Note that some studies have quoted higher percentage estimates, but this generally refers to the percentage of natural gas used for electricity generation (about 11 trillion cubic feet), rather than the full set of uses including residential, commercial, industrial, and transportation sectors.
Additionally, a California study found the state had the theoretical potential to produce approximately 90 billion cubic feet. In 2020, California consumed 2.1 trillion cubic feet of fossil gas, an upper bound of 4 percent of the supply that could potentially be met with RNG. A 2021 study for Philadelphia Gas Works found that “decarbonized gasses…are limited in terms of commercialization or total availability” and that “a full transition to decarbonized gasses in Philadelphia would likely require significant amounts of synthetic natural gas, a source of methane that is not yet commercialized.”
[12] For instance, a 2021 American Gas Association report assumes over 5 quadrillion BTUs of RNG will be used (excluding any used for electricity generation), over ten times higher than the NREL bound on maximum methane potential quoted above.
[13] A 2019 report by the American Gas Foundation itself found that RNG is likely to be available at costs of $7/MMBtu to $45/MMBtu. A 2016 report for the California Air Resources Board found that costs per MMBTU for RNG ranged from $30 to over $100 for dairies, $15 to $22 for municipal solid waste, $7 and over $50 for landfills, and between $9 and over $50 for wastewater treatment plants. According to the EIA, the city gate price of fossil gas is about $3.30/MMBTU. In short, the price of RNG varies between 2 and 15 times as expensive as fossil gas.
Under the most optimistic circumstances at very low production volumes, these data imply that RNG is over twice as expensive as fossil gas. As more RNG is produced, less optimal sources must be used, driving up the price and exacerbating the differential with fossil gas. For example, just 20 percent of the potential RNG resource is accessible at two times the price of fossil gas. In producing just half of the potential RNG resource, the price jumps to four times the price of fossil gas. By the time we are producing nearly the total technical potential, the price is over 15 times as expensive.
[14] This is based on estimates from the EIA’s Winter Fuels Outlook, which estimates natural gas bills during this winter will cost households $931 on average.
[15] For instance, see this 2022 article comparing the costs of winter heat between fossil fuels and electric heat pumps.
[16] These include the use of natural gas in industry as a feedstock to produce chemicals, rather than purely as an energy source.
[17] This 2020 EPA publication outlines the formations of the relevant pollutants (NOx, PM2.5, and benzene). The predominant mechanism of NOx formation is thermal, and happens simply because nitrogen and oxygen molecules are present in a high temperature zone. Benzene (C6H6) and PM2.5 (usually larger molecular weight hydrocarbons) are principally created through incomplete combustion, which is governed by the features of fire chamber and gas flow.
[18] A growing body of research establishes the link between residential gas appliances and harmful health effects, including childhood asthma, adult cancers, and dementia. A 2013 review article established a 42 percent increase in likelihood of asthma for children living in homes with gas stoves. A 2022 article estimated that 12.7% of current childhood asthma is attributable to gas stoves. A 2022 article documented gas stoves causing unsafe levels of benzenes, which have been linked to cancers. A 2019 review article and a 2021 article both established a link between the pollutants produced by gas stoves (PM2.5 and NOx) and an increased risk of dementia and cognitive decline.
